DESICCANT AIR DRYER 250 AND 300 CFM

Air Dryer
DESICCANT AIR DRYER 250 AND 300 CFM

This desiccant air dryer removes moisture from your compressed air to protect your equipment and process.

This equipment dries your air to a standard dew point of -40⁰C. This makes it ideal for an outdoor or cold zone application where the working environment is below freezing. It can also be required to meet the specific needs of your equipment.

With its simple design, it is easy to operate and maintain.

CSA approved

Available on demand Contact us for purchase

TECHNICAL SHEET
FEATURES	XCe250	XCe300
VOLTAGE	120 V SINGLED-PHASED	120 V SINGLED-PHASED
CFM	250	300
DEW POINT	-40°F	-40°F
OPERATING PRESSURE	60 / 150 PSIG	60 / 150 PSIG
PRE-FILTRATION REQUIRED	coalescent 0,01 um	coalescent 0,01 um
POST-FILTRATION REQUIRED	coalescent 1 um	coalescent 1 um
INPUT/OUTPUT CONNECTION	1-1/2" NPT	1-1/2" NPT
LENGHT (in)	45"	45"
WIDTH (in)	32"	32"
HEIGHT (in)	70"	70"
WEIGHT	460 LBS	460 LBS
DESSICANT WEIGHT	340 LBS	340 LBS
