FREON-TYPE AIR DRYER 1000 TO 2000 CFM

Air Dryer
FREON-TYPE AIR DRYER 1000 TO 2000 CFM

This freon-type air dryer removes moisture from your compressed air to protect your equipment and process.

This dryer provides a constant dew point at 3⁰C. Perfect for an indoor application, where the working environment is never below freezing.
This dryer offers low-pressure drops and remains efficient at its limiting temperatures (70⁰C air inlet and 50⁰C ambient).

Simplified control.

Warranty:
Two years with coalescing filter (installed at dryer inlet).

CSA approved

Available on demand Contact us for purchase

TECHNICAL SHEET
FEATURES	ACT-1000	ACT-1250	ACT-1500	ACT-1750	ACT-2000
VOLTAGES \| UQ	575 THREE-PHASED	575 THREE-PHASED	575 THREE-PHASED	575 THREE-PHASED	575 THREE-PHASED
AMPERAGES \| UQ	5,1 A	6 A	7,2 A	8 A	9,4 A
CFM	1000	1250	1500	1750	2000
GAS	R407C	R407C	R407C	R407C	R407C
INPUT/OUTPUT CONNECTION	3" 150#FL.	3" 150#FL.	4" 150#FL.	4" 150#FL.	4" 150#FL.
LENGHT (in)	31,1"	31,1"	44,7"	44,7"	44,7"
WIDTH (in)	39,4"	39,4"	47,4"	47,4"	47,4"
HEIGHT (in)	57,7"	57,7"	68,7"	68,7"	68,7"
WEIGHT	606 LBS	686 LBS	1168 LBS	1283 LBS	1312 LBS
